ATEK Mini 8-Channel Indoor LoRaWAN Gateway (UG63)

The ATEK UG63 is a compact, lightweight (158 g) indoor LoRaWAN gateway that fills coverage gaps in basements, parking levels, and back corridors. It packet-forwards traffic from up to ~2,000 nodes and pairs with a UG56 / UG65 fleet to extend reach.

• SX1302 8-channel concentrator (half-duplex), typ. 1.3 W draw; embedded network server for up to 20 devices
• Ethernet plus optional integrated 4G LTE Cat-1 backhaul with GSM fallback (Micro SIM) for sites without a wired drop
• Compatible with the ATEK Cloud LNS, The Things Stack, ChirpStack, and AWS IoT Core; MQTT(s)/HTTP(s) API
• Powered by USB-C, DC 5-12 V, or 802.3af PoE via splitter; desktop, wall, or ceiling mounting
• LoRaWAN bands EU868 / US915 / AU915; CE, FCC, RoHS certified
